| 1- |
|
|
12119 |
1 |
Power Unit - 1 Phase, 15000 |
Contact |
| 1- |
|
|
12089 |
1 |
Power Unit - 3 Phase, 15000 |
Contact |
| 1- |
|
|
12087-19 |
1 |
Power Unit - 1 Phase, 18000 |
Contact |
| 1- |
|
|
12089-19 |
1 |
Power Unit - 3 Phase, 18000 |
Contact |
| 2- |
|
BH-7234-05 |
12100 |
2 |
Equalizer Cable 15000/18000 |
$122.48 |
| 2- |
|
BH-7234-06 |
12019 |
2 |
Equalizer Cable 15002/18002 |
$126.24 |
| 3- |
|
BH-7226-13 |
31019 |
6 |
Cable Sheave / Pulley |
$102.09 |
| 4- |
|
BH-7226-80 |
31020 |
6 |
Washer |
$5.28 |
| 5- |
|
BH-7203-041 |
31021 |
6 |
Retaining Ring |
$12.27 |
| 6- |
|
|
A2158 |
2 |
Clevis Pin |
Contact |
| 7- |
|
|
A1153 |
1 |
Hex Flange Head Capscrew |
Contact |
| 8- |
|
|
A1154 |
1 |
Hex Flange Nut |
Contact |
| 9- |
|
BH-7234-394 |
A1122-12 |
1 |
Hose Clamp for 3/8" Hose |
$3.33 |
| 10- |
|
BH-7229-37 |
12045 |
1 |
Limit Switch |
$138.99 |
| 11- |
|
BH-7234-411 |
36065 |
2 |
Shoulder Bolt |
Contact |
| 12- |
|
|
31115 |
2 |
1/4" Flat Washer |
Contact |
| 13- |
|
|
70081 |
2 |
Keps Nut |
Contact |
| 14- |
|
BH-7234-205 |
12075 |
1 |
Overhead Shutoff Bar, Only |
Contact |
| 14- |
|
BH-7234-206 |
12074 |
1 |
Overhead Shutoff Bar Assembly |
Contact |
| 15- |
|
BH-7225-68 |
31129 |
1 |
Cushion for Shutoff Bar |
$3.48 |
| 16- |
|
|
A2159 |
4 |
Hex Head Capscrew 3/8"-16NC x 3" |
Contact |
| 17- |
|
BH-7234-217 |
12093 |
1 |
Arm Restraint Kit (1 Arm) 15/18 Includes #18-21. Does not include #22 |
$138.07 |
| 18- |
|
BH-7234-217A |
12060 |
4 |
Link Weldment Included in BH-7234-217 |
$49.98 |
| 19- |
|
BH-7229-40 |
31108 |
4 |
Arm Restraint Insert Included in BH-7234-217 |
$53.78 |
| 20- |
|
BH-7229-60 |
31109 |
4 |
Compression Spring Included in BH-7234-217 |
$1.66 Original price was: $1.66.$0.90Current price is: $0.90. |
| 21- |
|
BH-7234-216 |
12096 |
4 |
Sleeve Weldment Included in BH-7234-217 |
$227.15 |
| 22- |
|
|
31112 |
8 |
Socket Head Capscrew |
Contact |
| 23- |
|
BH-7234-208 |
B12062 |
4 |
Screw-Up Adapter Assembly (Not Frame Engaging) Includes #24-28 |
$343.35 |
| 24- |
|
BH-7235-547 |
B12063 |
4 |
Foot Pad Weldment Included in BH-7234-208 |
Contact |
| 25- |
|
BH-7101-00 |
482365 |
4 |
Rubber Pad, Bolt-On Style Included in BH-7234-208 |
$16.11 |
| 26- |
|
|
B12257 |
4 |
Retaining Ring Included in BH-7234-208 |
Contact |
| 27- |
|
|
B12067 |
4 |
Threaded Insert Included in BH-7234-208 |
Contact |
| 28- |
|
BH-7234-314 |
B1068 |
8 |
Hex Flange Head Screw Included in BH-7234-208 |
$2.41 |
| 29- |
|
BH-7234-128-15 |
|
1 |
Screw-Up Adapter Assembly (Frame Engaging) |
$260.31 |
| 30- |
|
BH-7232-01U |
A1104-H |
1 |
Urethane Snap-In Pad (1) |
$15.51 |
| 30- |
|
BH-7232-01OHD |
A1104-Hx |
1 |
Octagon HD Rubber Pad (1), Alt. to Urethane |
$16.50 |
| 30- |
|
BH-7232-01OHD-4 |
A1104-Hx |
1 |
Octagon HD Rubber Pad Kit (4), Alt. to Urethane |
$61.16 |
| 31- |
|
BH-7234-212 |
12021 |
8 |
Slider Block |
$37.44 |
| 32- |
|
BH-7234-207 |
12046 |
4 |
Swing Arm Pin |
$213.11 |
| 33- |
|
BH-7234-214K |
12048-1 |
4 |
Arm Assembly for 15/18 |
Contact |
| 34- |
|
BH-7234-214 |
12049 |
4 |
Outer Swing Arm 15/18 |
Contact |
| 35- |
|
BH-7234-215 |
12054 |
4 |
Inner Swing Arm 15/18 |
Contact |
| 36- |
|
|
12072 |
4 |
Socket Head Capscrew 1/2"-13 x 5/8" |
Contact |
| 37- |
|
|
12084 |
4 |
Internal Tooth Lockwasher |
Contact |
| 38- |
|
BH-7234-210 |
12069 |
4 |
4" Nesting Height Extension |
$81.63 |
| 38- |
|
BH-7234-208-5 |
12069x |
1 |
5" Nesting Height Extension |
Contact |
| 39- |
|
BH-7234-211 |
12068 |
2 |
8" Nesting Height Extension |
$158.54 |
| 40- |
|
BH-7234-211H |
12071 |
2 |
Adapter Organizer Rack |
Contact |
| 41- |
|
BH-7234-289 |
15075 |
2 |
Hydraulic Cylinder (69" Stroke) |
$3,282.17 |
| 41- |
|
BH-7231-37 |
|
1 |
Seal Kit for 2-1/2" Bore x 69" Pacoma Cylinder (some models) Call with Serial # from Cylinder to Confirm Seal Kit |
$72.65 |
| 42- |
|
BH-7234-239 |
12111 |
2 |
Cylinder Spacer |
Contact |
| 43- |
|
BH-7233DX-1135 |
16167 |
3 |
90° Elbow #6 SAE x #6 JIC |
$21.99 |
| 44- |
|
BH-7234-804 |
12256 |
1 |
Hose Assembly-Idler Side |
Contact |
| 45- |
|
BH-7234-805 |
12539-024 |
3 |
Extension Hydraulic Line 15002/18002 |
$130.46 |
| 46- |
|
BH-7234-803 |
12258 |
1 |
Hose Assembly-Power Side |
$123.48 |
| 47- |
|
BH-7234-807 |
12257 |
1 |
Hose Assembly for Power Unit |
$200.41 |
| 48- |
|
BH-7234-608 |
39103 |
1 |
Hydraulic Tee Fitting |
$16.59 |
| 48- |
|
BH-7226-81 |
31025 |
1 |
Hydraulic Line Clamp |
$1.27 Original price was: $1.27.$0.69Current price is: $0.69. |
| 49- |
|
|
40085 |
1 |
Hex Flange Nut 1/4"-20 |
Contact |
| 50- |
|
|
A2125 |
1 |
Hex Flange Bolt 1/4"-20 x 3/4" |
Contact |
| 51- |
|
|
12025 |
1 |
Column - Power Side |
Contact |
| 52- |
|
|
12026 |
1 |
Column - Idler Side |
Contact |
| 53- |
|
|
12022 |
2 |
Column Extension for 15002, 18002 |
Contact |
| 53- |
|
|
12116H |
1 |
Column Extension Pack for 15000 / 18000 |
Contact |
| 53- |
|
|
12102 |
2 |
Column Extension for 15000, 18000 |
Contact |
| 53- |
|
|
12117H |
1 |
Column Extension Pack for 15002 / 18002 |
Contact |
| 54- |
|
|
12007 |
2 |
Carriage 15000 |
Contact |
| 54- |
|
|
12007-18 |
2 |
Carriage 18000 |
Contact |
| 55- |
|
BH-7229-70M |
37072 |
2 |
Lock Cover, Molded Plastic (Snap On) |
$26.20 |
| 55- |
|
BH-7229-70 |
37072x |
1 |
Lock Cover, Metal (Snap On) |
$91.81 |
| 56- |
|
BH-7234-203 |
12039 |
1 |
Overhead Channel |
Contact |
| 57- |
|
BH-7512-92 |
|
1 |
Shim Assortment (3 sizes, 150 pcs) |
$81.33 |
| 58- |
|
|
|
1 |
Wedge Anchor |
Contact |
| 59- |
|
BH-7070-K |
SVI Exclusive |
1 |
Power Station (for 2-Post Lift) |
$474.85 |
| 60- |
|
|
|
1 |
Wheel Spotter Dish Kit - Single Position - with Anchors |
Contact |
| 60- |
|
|
|
1 |
Wheel Spotter Dish Kit - Dual Position - with Anchors |
Contact |
| 61- |
|
BH-7077-02-2S |
SVI Exclusive |
1 |
SVI DoorJammer PRO™ Car Door Protector 12"Tall (pair) |
$284.35 |
| 61- |
|
BH-7077-02-2 |
SVI Exclusive |
1 |
SVI DoorJammer PRO™ Car Door Protector 24"Tall (pair) |
$546.90 |
