BH-7152-09 |
12-1215K1 |
1 |
Cable & Sheave KIT for 12000, 12000WT and 12000QLC (not pictured) |
Contact |
| 1- |
|
BH-7151-59 |
12-4123A |
1 |
Safety Dog Assembly |
$110.38 |
| 2- |
|
BH-7152-20 |
12-4122A |
1 |
Safety Dog Assembly with Sensor |
Contact |
| 3- |
|
BH-7154-56 |
12-4124A |
1 |
Safety Dog Assembly |
$183.96 |
| 4- |
|
BH-7152-21 |
12-4121A |
1 |
Safety Dog Assembly with Sensor |
Contact |
| 5- |
|
BH-7154-57 |
B121119-02 |
1 |
LH Torsion Spring |
$27.82 |
| 6- |
|
BH-7154-58 |
B121119-01 |
1 |
RH Torsion Spring |
$27.82 |
| 7- |
|
|
A00003-12 |
1 |
Plain Washer 3/4” |
Contact |
| 8- |
|
BH-7154-59 |
12-4110A |
1 |
Safety Dog Mounting Pin Assembly |
Contact |
| 9- |
|
|
A00030-14 |
1 |
Cotter Pin 3/16 x 1-3/4 |
Contact |
| 10- |
|
|
A00004-32 |
1 |
Hex Bolt 1/4-20 x 4 |
Contact |
| 11- |
|
|
A00006-36 |
1 |
Hex Capscrew 3/8-16x4-1/2 |
Contact |
| 12- |
|
BH-7154-63 |
A00007-06 |
1 |
Security Locknut 3/8-16 |
Contact |
| 13- |
|
|
A00002-06 |
1 |
Split Washer 3/8 |
Contact |
| 14- |
|
BH-7154-64 |
12-4129 |
1 |
Guide Roller |
Contact |
| 15- |
|
BH-7154-65 |
12-1196 |
1 |
Safety Release Bracket |
Contact |
| 16- |
|
BH-7154-66 |
X00089 |
1 |
Hair Pin Cotter 1/2” |
Contact |
| 17- |
|
|
A00098-04 |
1 |
Hex Jam Nut 1/4-28 |
Contact |
| 18- |
|
BH-7151-26 |
X00097-10 |
1 |
Internal Tooth Lockwasher 5/8 |
$5.16 |
| 19- |
|
BH-7152-06 |
A00095 |
1 |
Air Cylinder |
$91.03 |
| 20- |
|
BH-7152-25 |
A00082-09 |
1 |
Elbow 5/32 to 1/8 NPT |
$22.76 |
| 21- |
|
BH-7154-67 |
A00084-04 |
1 |
Pneumatic Tubing 5/32 x 13-3/8 |
Contact |
| 22- |
|
BH-7151-55 |
A00082-08 |
1 |
Tee 5/32 x 5/32 x 5/32 |
Contact |
| 23- |
|
BH-7154-68 |
A00084-05 |
1 |
Pneumatic Tubing 5/32 x 94-3/4 |
Contact |
| 24- |
|
BH-7154-69 |
A00084-02 |
1 |
Pneumatic Tubing 5/32 x 10 |
Contact |
| 25- |
|
BH-7154-70 |
A00082-07 |
1 |
Branch Tee 5/32 x 5/32 x 1/4 |
Contact |
| 26- |
|
BH-7154-71 |
A00084-06 |
1 |
Pneumatic Tubing 5/32 x 190-1/2 for 12000, 12000S & 12000WT |
Contact |
| 27- |
|
BH-7154-72 |
A00082-06 |
1 |
Bulkhead Fitting 1/4 x 1/4 |
Contact |
| 28- |
|
BH-7154-73 |
A00094-01 |
1 |
Pneumatic Tubing 1/4 x 74-1/2 |
Contact |
| 29- |
|
BH-7153-94 |
A00082-13 |
1 |
Male Connector 1/4 x 1/4 |
$10.33 |
| 30- |
|
BH-7157-59 |
X00096 |
1 |
Air Valve |
$462.53 |
| 31- |
|
|
A00001-04 |
1 |
Hex Nut 1/4-20 |
Contact |
| 32- |
|
|
A00008-12 |
1 |
Hex Bolt 1/2-13 x 1-1/2 |
Contact |
| 33- |
|
BH-7154-76 |
12-1110 |
1 |
Wheel Stop |
Contact |
| 34- |
|
|
A00008-14 |
1 |
Hex Bolt 1/2-13 x 1-3/4 |
Contact |
| 35- |
|
|
A00001-08 |
1 |
Hex Nut 1/2-13 |
Contact |
| 36- |
|
|
A00001-05 |
1 |
Hex Nut 5/16-18 |
Contact |
| 37- |
|
|
A00002-05 |
1 |
Split Lockwasher 5/16 |
Contact |
| 38- |
|
|
A00003-05 |
1 |
Plain Washer 5/16 |
Contact |
| 39- |
|
BH-7154-79 |
12-1109 |
1 |
Ramp Pin |
Contact |
| 40- |
|
BH-7150-66 |
12-1121 |
1 |
Ramp Roller |
$15.33 |
| 41- |
|
|
X00056-08 |
1 |
Cotter Pin 3/32 x 1 |
Contact |
| 42- |
|
|
A00003-06 |
1 |
Plain Washer 3/8” |
Contact |
| 43- |
|
BH-7074-94-25 |
X00133 |
1 |
Anchor 5/8 x 4-3/4 |
$122.77 |
| 44- |
|
BH-7154-22 |
12-2003A |
1 |
Column Weldment - Idle |
Contact |
| 45- |
|
BH-7154-23 |
12-2004A |
1 |
Column Weldment - Drive |
Contact |
| 46- |
|
|
12-3030A |
1 |
Track Weldment Idle 12000WT |
Contact |
| 47- |
|
|
12-3029A |
1 |
Track Weldment Drive 12000WT |
Contact |
| 48- |
|
BH-7154-26 |
12-4011A |
1 |
Crosstube Weldment - Drive |
Contact |
| 49- |
|
BH-7154-27 |
12-4012A |
1 |
Crosstube Weldment - Idle |
Contact |
| 50- |
|
BH-7152-29 |
12-1133A |
1 |
RH Ramp Assembly 12000WT & WTS |
Contact |
| 51- |
|
|
B123117 |
1 |
Hydraulic Cylinder |
Contact |
| 52- |
|
BH-7154-29 |
12-3113 |
1 |
Cylinder Mounting Pin |
Contact |
| 53- |
|
F-CP-187-2000 |
A00030-16 |
1 |
Cotter Pin 3/16 x 2 |
$2.00 |
| 55- |
|
BH-7151-34 |
A93109-02 |
1 |
Hex Pipe Nipple 1/4 -1/4 NPT |
Contact |
| 56- |
|
BH-7153-37 |
A93108-05 |
1 |
Female Elbow 3/8 x 1/4 |
$43.31 |
| 57- |
|
BH-7154-32 |
12-3126 |
1 |
Hydraulic Tube 3/8 x 104-1/2 for 12000 & 12000WT |
Contact |
| 58- |
|
BH-7154-33 |
A93108-11 |
1 |
Bulkhead Fitting 3/8 |
Contact |
| 59- |
|
BH-7154-34 |
12-1118A |
1 |
Hydraulic Hose Assembly 3/8 |
$145.00 |
| 60- |
|
BH-7154-35 |
A93108-01 |
1 |
Male Elbow 3/8 x 3/8 |
Contact |
| 61- |
|
BH-7154-36 |
B121115 |
1 |
Hydraulic Power Unit |
Contact |
| 62- |
|
BH-7154-37 |
12-3109A |
1 |
End Plate Assembly |
Contact |
| 63- |
|
|
A00023-28 |
1 |
Roll Pin 1/4 x 1-3/4 |
Contact |
| 64- |
|
BH-7154-38 |
12-3141 |
1 |
Cylinder Rd End Guide |
$55.63 |
| 65- |
|
|
A00001-18 |
1 |
Hex Nut 1-1/8-7 |
Contact |
| 66- |
|
|
A00060-18 |
1 |
Hex Jam Nut 1-1/8-7 |
Contact |
| 71- |
|
|
A00007-14 |
1 |
Security Locknut 7/8-9 |
Contact |
| 72- |
|
|
A00003-14 |
1 |
Plain Washer 7/8 |
Contact |
| 73- |
|
BH-7151-31 |
12-1104A |
1 |
Crossbeam Sheave (7” OD) |
$199.77 |
| 74- |
|
BH-7150-63 |
12-1212A |
1 |
Double Sheave Assembly |
$618.76 |
| 75- |
|
BH-7150-67 |
12-1213A |
1 |
Single Sheave Assembly |
$577.76 |
| 76- |
|
BH-7150-64 |
12-3122A |
1 |
Sheave Axle Assembly |
$104.02 |
| 77- |
|
BH-7151-30 |
12-1111A |
1 |
Sheave Axle Assembly - Crosstube |
$141.98 |
| 78- |
|
|
X00061-08 |
1 |
Socket Capscrew 1/4-20 x 1 |
Contact |
| 79- |
|
BH-7153-70 |
A00007-04 |
1 |
Security Locknut 1/4-20 |
Contact |
| 80- |
|
|
A00004-08 |
1 |
Hex Bolt 1/4-20 x 1 |
Contact |
| 81- |
|
|
A00003-04 |
1 |
Plain Washer 1/4 |
Contact |
| 82- |
|
|
A00002-04 |
1 |
Split Lockwasher 1/4 |
Contact |
| 83- |
|
BH-7154-49 |
12-1128 |
1 |
Sheave Cover |
Contact |
| 84- |
|
|
A00004-04 |
1 |
Hex Bolt 1/4-20 x 1/2 |
Contact |
| 85- |
|
BH-7154-50 |
12-2116A |
1 |
Safety Channel Assembly |
Contact |
| 86- |
|
|
A00001-16 |
1 |
Hex Nut 1-8 |
Contact |
| 87- |
|
|
A00003-16 |
1 |
Plain Washer 1” |
Contact |
| 88- |
|
|
A00060-16 |
1 |
Hex Jam Nut 1-8 |
Contact |
| 89- |
|
|
A00008-10 |
1 |
Hex Bolt 1/2-13 x 1-1/4 |
Contact |
| 90- |
|
BH-7150-80 |
A00003-08 |
1 |
Plain Washer 1/2 |
Contact |
| 91- |
|
|
A00002-08 |
1 |
Split Lockwasher 1/2 |
Contact |
| 92- |
|
|
12-1132A |
1 |
LH Ramp Assembly 12000WT & WTS |
Contact |
